Technical Specifications

DANGER

Danger of death when operated in potentially explosive areas!

▶The system must not be installed or operated in potentially explosive areas.

Ambient conditions
Working temperature	0 … +50 °C (+32 … 122 °F)
Storage temperature	-10 … +70 °C (+14 … +158 °F)
Humidity during operation	5 … 90 %, non-condensing
Place of installation	Closed, dry building

Exceptions to these conditions are only possible after consultation with BST.

Power supply
Voltage	24 V⎓ ±10 % (including ripple) (from the web guiding controller)
Current consumption (per sensor slide)	max. 0.3 A (including one edge sensor IR2011 or US2010)
Power consumption (per sensor slide)	7.2 W (without external load)
Reverse polarity protection	Yes
Connection	Supply via CAN bus interface (X11 / X21)

Protection category
Protection category	IP42

Sensor positioning
Sensor slide positioning speed	max. 120 mm/s
Repeatability	±0.05 mm per sensor slide*
Linearity deviation	±0.15 mm per sensor slide**

* measured with IR2011/40 sensor at a temperature of 20 °C

** measured with IR2011/40 sensor at a temperature of 20 °C and a module length of 1,800 mm

CAN bus interface (X11, X21)
Transmission rate	500 kBit/s, no galvanic isolation
Connection	4-pin micro-style connector M8 (DIN IEC 61076)
Max. connecting cable length	10 m

Emissions
Continuous sound level (A evaluated, equivalent)	< 70 dB(a)

UL Certification
This product is certified according to the following directives: UL 2011, Outline of Investigation for Machinery, Edition 7, Issue Date 11/10/2022 CSA C22.2 No. 14, Industrial Control Equipment, Edition 13, Revision Date 06/2022 Information on the manufacturer, the product and the UL standards met can be found in the UL database under the following file number: E543387

UL Certification

This product is certified according to the following directives:

UL 2011, Outline of Investigation for Machinery, Edition 7, Issue Date 11/10/2022
CSA C22.2 No. 14, Industrial Control Equipment, Edition 13, Revision Date 06/2022

Information on the manufacturer, the product and the UL standards met can be found in the UL database under the following file number: E543387

The UL certification applies exclusively in conjunction with the ekr CON 610, ekr CON 610 net web guiding controller.

RoHS Conformity
This product complies with the EU Directive 2011/65 (known as the RoHS* Directive). The limits values for hazardous substances in electrical and electronic equipment specified there are not exceeded by this product. * Abbreviation for Restriction of Hazardous Substances

RoHS Conformity

This product complies with the EU Directive 2011/65 (known as the RoHS* Directive).
The limits values for hazardous substances in electrical and electronic equipment specified there are not exceeded by this product.

* Abbreviation for Restriction of Hazardous Substances

Dimensions and total weight
See overview drawings in the Appendix.
