Switching On the Master-Slave Guiding

WARNING
Danger of death from actuator movements!

Parts of your body could be crushed, cut or hit.

  • ▶Make sure that no persons remain in the vicinity of the pivot / traversing area of machine components that are positioned by the actuator.
  1. Select the desired guiding mode (see Guiding Modes).

  1. Activate Automatic operating mode.
  1. Set the Slave web guiding setpoint as follows:
  • Move sensor 2 across the web running direction or adjust the guiding setpoint using the arrow keys.
