Cable Routing
WARNING
Severe injuries and damage to assets caused by incorrect cable routing.
Poorly routed cables can cause tripping, spills and consecutive accidents.
- ▶Always route cables strain-relieved and well anchored.
- ▶Ensure that no tripping or catching points are generated.
- ▶Do not bend/kink cables; observe the minimum bending radius.
- ▶Maintain a minimum distance of at least 25 mm between the cables and moving parts of the machine.
- ▶Route the cables so that they do not rub or become crushed, cut or caught.
- ▶Tighten up the securing screws in the plug connections.
- ▶Route signal cables separately from supply cables as signal cables are sensitive to interference.
Rotate the smartphone by 90 degrees to show the entire table.
① | Cable duct | ③ | Supply cable |
② | Signal cable |
|
|
- ▶Establish cable connections between the components according to the connecting diagram.
