Switching the Configurable Displays and Setting Menus On/Off

The selection of the configurable displays and setting menus that can be called up using the swiping function (see Configurable Displays and Setting Menus) is done in a special setup menu.

Setup menu for the configurable displays and setting menus
Rotate the smartphone by 90 degrees to show the entire table.

Symbol

Function

Description

Displaying the web width

See Displaying the Web Width

Adjusting the oscillation amplitude

See Adjusting the Oscillation Amplitude

Adjusting the oscillation frequency

See Adjusting the Oscillation Frequency

Setting the guiding setpoint

See Adjusting the Guiding Setpoint with the Setting Menu

Operating the positioning unit

See Positioning Unit

Switching on the configurable displays and setting menus

  1. Press the Configurable Displays and Setting Menus button.
  • The setup menu for the configurable displays and setting menus is displayed.
  1. Select the desired display or setting functions that can be called up using the swiping function by tapping the corresponding button.
  • The buttons selected are displayed with a blue background.

  1. Press the button to confirm the selection.
  • The setup menu is displayed.

When swiping on the touchscreen the displays and setting menus selected are displayed one after the other.
